VEDO Professional 3-Channel Portable Sound Mixer Console Computer Input 48v Power Model Number Certification Origin
Descrição do Produto
Technical parameters: 1.Frequency response(-3dB):2Hz~76Khz 2.Total harmonic distortion:<0009%(T.H.D.) 3.Signal to Noise Ratio(SNR):112dB 4.Channel 1input sensitivity:Mic(XLR)Min:500mV~Max 7mV5.Channel 2/3 input sensitivity:Line (TRS) Min: 620mV~Max 7.6mVLine(TRS/RCA)Min:2.55V~Max:60mV6. Each channel has 4 EQ frequency bands: High + 15dB (18KHz) Mid High + 15dB (2.4KHZ)Mid Low+15dB(240Hz)Low15dB(30Hz)7. Channel 1 input lmpedance: Mic (XLR): Unbalanced 4K Ohms Balanced 8K OhmsLine(TRS):Unbalanced 8.5K Ohms Balanced 17K Ohms8. Channel 2 Input lmpedance: Line (TRS): unbalanced 10K Ohms Line (RCA):unbalanced 10K Ohms 9.Output impedance: Main Out (P10/RCA): 47R Aux Out (P10/RCA): 47R10.Maximum output level: Main Out (P10/RCA): 18 dBu/6.3Vac Aux Out (P10/RCA): 18 dBu/6.3Vac 11.Input output level MIC(-60dB)LINE ONPUT(-40dB) 12.Power supply voltage: 9~16 Vdc 13.Maximum consumption:350 mA 14.Remote input(REM connector):9-16 Vdc 15.Remote output(REM connector):350 mA 16.Dimensions(width xheight x depth):134x42x220mm 17.Weight: 0.70Kg
